Frey Medical AP-300 Perimeter
Perimeter AP-300 is a modern and innovative Visual Field Analyzer that meets global standards for excellence around visual sensitivity testing, diagnosis and management of eye disease. Perimeter AP-300 as a visua field analyser platform of advanced diagnostics uses Kinetic and Static Perimetry, including white/white perimetry, blue/yellow (SWAP – Short wavelength automated perimetry) and Flicker (critical flicker fusion perimetry) for early glaucoma detection plus real Goldmann Kinetic Perimetry.
-
Improved patient comfort
-
Rapid testing times
-
Complete analysis modes
-
Multiple test capabilities
-
Accurate results
Complete test and data analysis system
Visual Field Analyzer AP-300 combines the features of static and kinetic parameters, offering a rich set of diagnostic techniques. Advanced application software provides unique functions analysis of patient results, making diagnosis easier and faster. Standard presentation of patient perimetry results allow the user to print a single test and present clinical changes in the visual field over time.
Kinetic perimetry
Kinetic perimetry is performed using stimuli of varying size, color, intensity and speed of movement (according to the standard adopted for kinetic perimetry). A single test can consist of up to 8 Isopters. For each isopter, individual stimuli parameters can be assigned, which broaden and enhance diagnostic range, enabling an improved clinical assessment.
Blue-on-yellow static perimetry
Static perimetry Blue-On-Yellow, presented by blue stimulus size V by Goldmann on a yellow background, enhances earlier diagnosis of glaucoma. A rich library of built-in test fields and strategies improves accuracy of diagnosis and documents changes in the field of view of the patient over time.
Test fields
Tests can be performed within standard testing area covering various ranges of angular field of view (up to 80 degrees for one eye). There are fields with concentric arrangement stimuli (i.e. Macula, 22 °, 30 °, 50 °, driving Wide, Glaucoma, Peripheral) or the rectangular system (i.e.. 10-2, 24-2, 30-2). The built-in editor allows the user to define specific tests of the test field. It is also possible to test the central vision (optional Fovea).
Targeted perimetry
The unique technology targeted perimetry allows the user to load previous fundus images and select area requiring investigation, and the perimetry examination will be focussed on the designated area. This technology allows for faster and more accurate examination of the area of interest.
Pattern calibration
Patients with large defects in the visual field or fields significantly deviating from the standard perimeter examination, can experience fatigue due to length of the examination. Pattern calibration is designed to improve the comfort of these patients and significantly reduces examination time. Pattern calibration technique can reduce examination time significantly by more than five minutes.
